Gameface now allows external code to hook into its profiling markers. User code can setup handler that will be called when Gameface is profiled and receive information on internal profiling events. This makes displaying profiling markers in external tools and/or systems. More information can be found in the Profiling documentation page. The documentation also illustrates how can Tracy can be used to profile Gameface

As part of the feature, there are also a few notable public API changes to Gameface:

  • cohtml::Library::EnableProfiling should be used instead of cohtml::System::EnableProfiling.
  • cohtml::LibraryParamsWithExternalRenderingLibrary::FileSystemWriter should be used instead of cohtml::SystemSettings::FileSystemWriter
  • cohtml::IProfileMarkersTracer and cohtml::LibraryParamsWithExternalRenderingLibrary::ProfileMarkersTracer can be used by client code to receive profiling events from Gameface

Changes to the renoir::RendererBackend interface

Section titled “Changes to the renoir::RendererBackend interface”
  • In this release, we have added a new rendering backend resource operation, void CopyTextureToTexture(Texture2DObject source, Texture2DObject destination, UpdateBox sourceRect, float2 destinationPoint);, to the renoir::RendererBackend interface. The idea behind it is to copy a region from one texture into a region of another texture. The sourceRect represents the region we wish to copy from the source texture, while the destinationPoint refers to the upper left corner of the destination region. The source and destination region are of the same size which is represented by sourceRect.Right - sourceRect.Left for the width and sourceRect.Bottom - sourceRect.Top for the height. The provided backends offer a reference implementation of the new method.

  • An existing renoir::RendererBackend method, void UpdateTexture(Texture2DObject texture, const Texture2D& description, UpdateBox* boxes, const void** newBytes, unsigned count, bool willOverwrite), has been slightly altered. It is known that newBytes is a list of pointers with the new data, with which the texture will be updated, however now if any pointer from this list is nullptr, its corresponding region should be cleared.

If you are using a custom backend, you will have to implement these changes on your end as well.

The minimum allowed text atlas texture size has been increased from 64px to 1024px due to internal refactoring of our font loading scheme. If you are using the TextAtlasWidth or TextAtlasHeight initialization parameters of the Rendering library to set a custom size, the value will now be clamped between 1024px and 8192px, rounded up to the nearest power of two.


API

Bumped the minimum required MacOSX version to 10.13+

API

Moved the EnableProfiling method from the System to the Library interface

API

Moved the FileSystemWriter implementation from the SystemSettings to the LibraryParams interface

API

Added CopyTextureToTexture method to the renoir::RendererBackend interface

API

Changed the UpdateTexture method of the renoir::RendererBackend to allow to clear regions of the texture

API

Changed the minimum allowed text atlas texture size to 1024px

API Unreal Engine

Enabled the GPU tessellator for SVGs by default

Feature

Added support for $0 - $4 to the inspector

Feature

Added support for enabling external profiling systems to receive events about internal profile markers

Feature

Added support for Webpack HMR and React Hot Loader

Feature Unreal Engine

Introduced LLM Scope tags for CPU memory tracking via the LLM Tracker

Enhancement

Changes to the the text children of a style element now change CSS

Enhancement

Added the property name and stack trace when accessing objects marked as destroyed with DestroyExposedObject from JavaScript

Enhancement

Added support for media query media types all, print and screen

Enhancement

Improved the performance of the Web Animation API implementation in cases when CSS animations animate more than one CSS property

Enhancement

Improved the performance of the the CSS animations when animating multiple properties with the same value type

Enhancement

Added two factor authentication sample UI

Enhancement

Added two factor authentication to the multiplayer UI sample

Enhancement

Added login and friends list sample UI

Enhancement Unity

Added ability to modify the SystemSettings with the OnSystemCreate delegate

Enhancement Unity

Added API reference documentation for the functions exposed by the Unity3D integration

Enhancement Unreal Engine

Made the Unreal Editor Live Reload feature to be enabled by default

Enhancement Unreal Engine

Added ICohtmlPlugin delegate for overriding the default FCohtmlInputPreprocessor

Fix

Use TextureBatchingHint to ensure correct calculation of GetUserGPUMemoryStats total and peak values

Fix

Replaced assert with JavaScript exception when ES6 module fails to load

Fix

Fixed stack-overflow crash when loading ES6 modules with very deep dependency tree

Fix

Fixed accumulating memory when videos are hidden or unloaded

Fix

Fixed calling audio stream pause callback on non-playing streams

Fix

Fixed incorrect drawing of SVGs used as background, border or mask image

Fix

Fixed mutation observer assert on document disposal

Fix

Fixed a crash due to missing temporary allocator when triggering events from worker threads

Fix

Fixed Linux samples compilation, linking and post-build steps

Fix

Added packaging of the missing ICU libraries for Linux

Fix

Fixed a race condition during textures destruction

Fix

Fixed the anti-aliasing artifacts for scaled circles and ellipses

Fix

Fixed WebSocket race condition during disconnecting

Fix Unity

Fixed not being able to connect the Dev Tools Inspector on every second play in the Unity3D editor

Fix Unity

Fixed resource loading issue on MacOS and iOS caused by white space in the StreamingAssets path

Fix Unreal Engine

Fixed colors of textures imported with the Unreal Editor texture import menu

Fix Unity

Fixed propagating the input with multiple Canvas On-Screen views
